CC-Link FieldLink Cable
Developed by Mitsubishi, CC-Link allows high speed communication between controllers and field devices. The CC-Link system is particularly popular in Asia and is used worldwide for time critical applications in conjunction with Mitsubishi Automation products. CC-Link is certified by CLPA and ensures product compatibility.
As a registered member of the CC-Link Partner Association, FS Cables offer a 3 core CC-Link cable for use on the CC-Link system, suitable for data rates up to 10MB/s, in either PVC or SWA (steel wire armoured) versions.
Image representative of product style, product supplied may vary.
- Registered member of the CC-Link Partner Association
- Suitable for data rates up to 10MB/s
- PVC or SWA for external applications
Construction
Plain copper conductors 20(7)AWG, foamed PE with a hard skin insulation, polyester tape, aluminium foil screen & 22(19)AWG tinned copper drain wire, tinned copper wire braid – 78% optical coverage, PVC sheath.
Only logged in customers who have purchased this product may leave a review.
SALES ENQUIRIES
Belcable's Products have Authorized Dealers in Middle east and United Kingdom.
Kindly Contact them to place Your Order.
CABLES HOUSE Cables & Wires Trading LLC
Cables House Cables & Wires Trading LLC Dubai. United Arab Emirates| Voltage Rating: | 300V |
| Temperature Rating: | |
| Fixed: | -20°C to +60°C |
| Nominal Impedance: | 110 Ohms |
| Capacitance @ 1hz: | 60pF/m |
| Conductor Resistance @ 20°C: | 37.8 Ohms/km |
| Data Rate: | 10MB/s |
| Colour Code: | Yellow, white, blue |
CFS-TCWB – Collective Foil Screen, Tinned Copper Wire Braid
